Curtis Industries Mounting Blocks for E1742 Penetrameter

Used when it is impractical to place the IQI directly on the object. Mounting blocks are supplied in sizes corresponding with ASTM E1742 IQI sizes. The material and thickness are marked on each block. All blocks are 57.2mm x 25.4mm (2.25” long x 1.0" wide). Standard materials available: Aluminum (6061), Brass, Copper, Cupro-Nickel, Inconel, Magnesium, Nickel, Stainless (304), Steel (1018), Titanium and Zirconium. Special materials also available: Aluminium (2014, 2024, 2219 or 7075), Cobalt, Haynes 25, Hastelloy (B, C or X), Inconel (625 or 718), Monel, Phosphorus-bronze and Waspaloy (up to 0.375" (9.53 mm)). Contact us to discuss the materials, options and/or receive a quote. See attached Data Sheet for the complete list.

Request for information on this product
